Online simulation of the конденсаторы параллельно соединенные circuit

This circuit shows that the capacitance of two capacitors connected in parallel equals the sum of the two individual capacitances. (The 10 mΩ resistor is needed to work around a problem with the simulator.)

This page is a utility for simulating конденсаторы параллельно соединенные online with specified initial values.

The online circuit simulator allows you to model circuit behavior in real time. You can change circuit parameters, add new elements, and observe their interactions. This is a useful tool for learning and experimenting with electronic circuits.
