Online simulation of the полосовой фильтр на варикапе circuit

This is a variable-bandwidth filter built with two varactors (varicaps). It is a tunable LC bandpass filter that provides selectivity of up to 20 dB at the edges of the 80 m band when tuned to the middle of the band. Varactors are used instead of capacitors.

This page is a utility for simulating полосовой фильтр на варикапе online with specified initial values.

The online circuit simulator allows you to model circuit behavior in real time. You can change circuit parameters, add new elements, and observe their interactions. This is a useful tool for learning and experimenting with electronic circuits.
