Online simulation of the простые линии передачи circuit

This is a simple circuit using a transmission line. Usually, when analyzing a circuit, the length of the wire is not important. But in this case the frequency is high enough that the time it takes electrical energy to cross the transmission line is longer than one cycle. The oscillation period is 25 nanoseconds, and the delay in the transmission line is 30 nanoseconds.

This page is a utility for simulating простые линии передачи online with specified initial values.

The online circuit simulator allows you to model circuit behavior in real time. You can change circuit parameters, add new elements, and observe their interactions. This is a useful tool for learning and experimenting with electronic circuits.
⚡ Circuit Online
Left-click — place/select · hover over an end (◯ highlights) and drag — stretch · wheel — zoom · middle/right-click — pan · double-click — settings
Basic Online Circuits Custom Circuits Create Your Own Circuit
