Online simulation of the ограничитель формы волны circuit

This circuit uses a diode to clip the top of the input triangle wave. Above 5.7 V, current flows through the diode and resistor and proportionally reduces the output voltage.

This page is a utility for simulating ограничитель формы волны online with specified initial values.

The online circuit simulator allows you to model circuit behavior in real time. You can change circuit parameters, add new elements, and observe their interactions. This is a useful tool for learning and experimenting with electronic circuits.
