This circuit generates sine and cosine waves. It combines two integrators. Since the integral of sine is negative cosine, and the integral of cosine is sine, we can generate both waves by feeding each integrator's output into the other's input. To hear the signal, increase the simulation speed and press the Play button.

This page is a utility for simulating генератор синусоидальной волны online with specified initial values.

The online circuit simulator allows you to model circuit behavior in real time. You can change circuit parameters, add new elements, and observe their interactions. This is a useful tool for learning and experimenting with electronic circuits.
