Online simulation of the шлюз передачи cmos circuit

This is a CMOS transmission gate, which acts as a switch. When the switch input is high, the 40 Hz signal can pass through the transmission gate. When the switch input is low, it cannot; the transmission gate acts as an open circuit. Normally a discrete MOSFET has its body terminal connected to the source terminal, but that does not work in this case. The source terminal of the n-MOSFET may have a higher voltage than the drain (and the drain of the p-MOSFET may be higher than the source), which could cause the body diode to conduct. Therefore, instead the MOSFETs must have a separate body terminal connected either to ground (for the n-MOSFET) or to the supply voltage (for the p-MOSFET).

This page is a utility for simulating шлюз передачи cmos online with specified initial values.

The online circuit simulator allows you to model circuit behavior in real time. You can change circuit parameters, add new elements, and observe their interactions. This is a useful tool for learning and experimenting with electronic circuits.
⚡ Circuit Online
Left-click — place/select · hover over an end (◯ highlights) and drag — stretch · wheel — zoom · middle/right-click — pan · double-click — settings
Basic Online Circuits Custom Circuits Create Your Own Circuit
